Tex Mix - 4 Mono Channels

This is a 4 mono channels expansion. Several of these modules can be added to provide more channels. Every channel features:

- Mono input

- Vactrol Gate (plug a CV into the GATE IN to modulate the volume of a channel, just like a classic VCA. When nothing is plugged in the GATE IN, the gate is normalled to fully open)

-SEND A control (switchable PRE/POST, in PRE mode the signal is present regardless to the channel volume control but only if the channel switch is in ON position)

-SEND B control (post-fader)

-PAN control (only affects the master bus)

-VOLUME control (affects the master, cue and POST sends, does not affect PRE-fader send)

-ON/OFF/CUE switch: ON - channel is routed to the master bus

OFF - channel is muted

CUE - channel is routed to the cue bus

  • 13 mA +12V
  • 8 mA -12V
